东莞标检产品检测有限公司
随着加入世贸组织，中国进出口商品品检需求与日俱增。为迎合这个趋势，香港标准及检定中心于中国广东省东莞市设立了第一间独立、非牟利的产品检测中心——「东莞标检产品检测有限公司」，并已于2008年举行开幕典礼，正式投入服务。该中心面积超过三万五千平方米，可为区内制造商提供一站式的全方位服务。服务包括：测试服务、检验服务、认证服务以及技术服务。
东莞标检已成功获得国家质量监督检验检疫总局（AQSIQ）所颁发的《从事进出口商品检验鉴定机构资格证书》。并成功取得多个国家和国际权威机构的认可，包括中国合格评定国家认可委员会（CNAS）、美国哥马克阻燃实验室（Govmark）及德国认可委员会（DAkkS)等。此外，东莞标检亦获中饮标（北京）安全饮品认证中心颁发授权实验室证书；电波暗室更取得美国联邦通讯委员会（FCC）和加拿大工业组织（IC）的认可，为长远发展奠定了稳健基础。
东莞标检未来几年将进一步扩大服务及认可范围，并投放更多资源用于发展实验室仪器设备及工作管理系统，为国内企业及制作商提供更全面的检测及认证服务，协助业界推动工商业界发展。
桌、椅服务范围（ASTM/EN 581：Part 1& Part2/3)：
EN 581-1:2006 Outdoor furniture –Seating and tables for camping, domestic and contract use Part 1: General safety requirement(s)
EN 581-2:2009Outdoor furniture - Seating and tables forcamping, domestic and contract use Part 2: Mechanical safety requirements and test methods for seating
Condition for use of the product : Domestic
Test item | Clause | Test Principle/Requirement(s) | Comment |
Edges and corners | Clause 5.1 | For seating, the edges and corners of the seat, back rest and arm rests which are directly in contact with the user when sitting , lying or reclining shall be rounded or chamfered. For table tops the edges and corners which are directly in contact with the user shall be rounded or chamfered. All other edges and corners of seating and tables, accessible during use shall be free from burrs or/and sharp edges. | |
Tubular components, holes and gaps accessible during use | Clause 5.2 | Tubular components,
holes and gaps accessible during use shall be covered if a Bottom of tubular legs shall be capped or plugged. |
Test item | Clause | Test Principle/Requirement(s) | Comment |
Sheer and squeeze points | Clause 5.3 | Unless The edges of parts moving relative to each other and creating Shear and squeeze points under the influence of powered mechanisms Shear and squeeze points shall be as specified in 5.1 | |
These shall be no accessible shear and squeeze points created by parts of furniture operated by powered mechanisms, e.g. mechanical springs, gas lifts. | |||
For seating, the loads applied during normal use can be found in ENV581-2, and for tables in EN 581-3. Shear and squeeze points are not acceptable if a hazard is created by the weight of user during the normal movements and actions, e.g. attempting to move the seating by lifting the seat or by adjusting the backrest. |
Test item | Clause | Test parameters | Comment | |
Domestic | ||||
Seat and back static load test | EN 1728:2000 | Seat :force N 10×10s(±2s)+1×30 min(±10s) Back :force N 10×10s(±2s)+1×30 min(±10s) | 1600 410 | |
Seat front edge static load test | EN 1728:2000 | Force, N 10×10s(±2s)+1×30 min(±10s) | 1300 | |
Seat and back fatigue test for seating | EN 1728:2000 6.7 | Cycles Seat : force, N Back bending moment N.m | 25000 1000 100 max | |
Fatigue test on back rest mechanism | See Annex A | Cycles Seat : Load, kg Force, N Back bending moment N.m | 10000 100 250 100 | |
Arm downwards static load test | EN 1728:2000 6.6 | Vertical force, N | 700 | |
Arm fatigue test | EN 1728:2000 6.10 | Cycles Force, N | 10000 400 | |
Leg forward static load test | EN 1728:2000 6.12 | Seat : Load, kg Horizontal force, N | 75 300 | |
Leg sideways static load test | EN 1728:2000 6.13 | Seat : Load, kg Horizontal force, N | 75 300 | |
Seat impact test | EN 1728:2000 6.15 | Drop height, mm 10 times | 180 | |
Foot rail static test for high seating | EN 1728:2000 6.4 | Vertical force, N | 1000 | |
Test item | Clause | Test parameters | Comment | |
Forward stability | EN 1022:2005 6.2 | Vertical force ,N Horizontal force, N t≥5s | 600 20 | |
Sideways overbalancing, all seating without arms | EN 1022:2005 6.4 | Vertical force , N Horizontal force, N t≥5s | 600 20 | |
Sideways overbalancing , all seating with arms | EN 1022:2005 6.5 | Vertically force for the seat : N Vertically force for the arms : N Horizontally force for the side of the arms: N t≥5s | 250 350 20 | |
Rearwards stability | EN 1022:2005 6.6 | Vertical force ,N Horizontal force: t≥5s | 600 F=80N H≥ | |
Instruction for use(visual check) | Clause 7.1 General | Name and address of the producer (manufacturer or supplier); Information regarding maintenance; Condition for use of the product (camping, domestic or contract). | ||
Clause7.2 Marking for mobile loungers | All mobile loungers not intended to be lifted and moved under the load specified in Table B.1 shall be marked with a pictogram as an example is shown in Figure 1 | |||
