YS-K22 给袋挂耳咖啡内外袋包装机

特  点 Characteristic

1、适用于咖啡粉、小颗粒状物料。

The machine is suitable for ground coffee and small particulate material.

2、采用特定的挂耳式滤网、三边封口、直接挂在杯子边缘，咖啡冲泡效果更好，且袋型美观,目前国外市场非常流行。

Adopt the special drip filter bag with three-sides sealing, which can be  directly hung against the cup edge to have a better brewing effect, moreover, the neat bag shape is a high fashion in the overseas markets.

3、本机具有自动完成制袋、计量、充填、封合、分切、计数、打印批号等功能。

The machine integrates automatic function, such as bag making, measuring, filling, sealing cutting, counting, batch number printing and other functions.

4、内袋为无纺布挂耳袋，冲泡方便且卫生。封口采用先进的超声波封，封口效果好，袋形美观。

The drip inner bag made of non-woven fabric, guarantees covenient and hygienic brewing. The sealing adopts the advanced  ultrasonic sealing, perfect sealing and beautiful bag type.

5、包装材料：内袋（玉米纤维、挂耳咖啡）；外袋PE复合膜，如：纯铝，镀铝等预制袋。

Packing material: PE composite film, such as: pure aluminum, aluminum plating and other prefabricated bags.

封口方式 Sealing Type

预置袋

技术参数

Technical Parameters

计量范围：5 - 10 g

Measuring Scope

内袋尺寸：长 ( L ) ：90 mm   宽 ( W ) ：90 mm

Inner bag size

外袋尺寸：长 ( L ) ：125 mm   宽 ( W ) ：100 mm

Outer bag size

包装速度：20-35 bags/min

Packing Speed

外型尺寸：1249 * 975 * 2243 mm

Dimension ( L * W * H )

整机重量：660 kg

Weight

总 功 率：AC220V / 50Hz / 3.7kw

Total Power

气    源：≥0.6m³/ min

Gas source
