ZoneDefender Pro Series

价格：

400

行业分类：电工电气/高压电器/防雷避雷产品

产品类别：

品　　牌：英国MTL浪涌保护器

规格型号：ZD16100,ZD16101,ZD16104,ZD16107,ZD16108,ZD16200,ZD16201

库　　存：50

生产商：英国MTL

产　　地：中国广东省深圳市

立即询价

联系方式

产品详情

ZoneDefender Pro Series

Model	Working voltage(V)	UL SVR 2nd Edition(V)	UL VPR 3rd Edition(V)	Limiting voltage		Ringwave @200A (V)	Up(kV)	Phase types
Model	Working voltage(V)	UL SVR 2nd Edition(V)	UL VPR 3rd Edition(V)	@ 3kA(V)	@10kA (In)(V)	Ringwave @200A (V)	Up(kV)	Phase types
80kA versions
ZD16100	120/240	400	500	470	780	0.8	60	Split phase 3 wire
ZD16101	120/208	400	500	470	780	0.8	60	Three phase 4 wire WYE
ZD16104	277/480	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16107	220/380	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16108	240/415	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
100kA versions
ZD16200	120/240	400	500	470	780	0.8	60	Split phase 3 wire
ZD16201	120/208	400	500	470	780	0.8	60	Three phase 4 wire WYE
ZD16202	120/240	400/800	500/1000	470/890	780/1200	0.8/1.2	60/75	Three phase 4 wire Delta
ZD16204	277/480	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16207	220/380	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16208	240/415	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
120kA versions
ZD16300	120/240	400	500	470	780	0.8	60	Split phase 3 wire
ZD16301	120/208	400	500	470	780	0.8	60	Three phase 4 wire WYE
ZD16302	120/240	400/800	500/1000	470/890	780/1200	0.8/1.2	60/75	Three phase 4 wire Delta
ZD16304	277/480	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16307	220/380	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
ZD16308	240/415	800	1000	890	1200	1.2	75	Three phase 4 wire WYE
160kA versions
ZD16400	120/240	400	500	430	650	0.7	50	Split phase 3-wire
ZD16401	120/208	400	500	430	650	0.7	50	Three phase 4-wire WYE
ZD16402	120/240	400/800	500/1000	430/770	650/1180	0.7/1.2	50/68	Three phase 4 wire Delta
ZD16404	277/480	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16407	220/380	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16408	240/415	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
200kA versions
ZD16500	120/240	400	500	430	650	0.7	50	Split phase 3-wire
ZD16501	120/208	400	500	430	650	0.7	50	Three phase 4-wire WYE
ZD16502	120/240	400/800	500/1000	430/770	650/1180	0.7/1.2	50/68	Three phase 4 wire Delta
ZD16504	277/480	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16507	220/380	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16508	240/415	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
240kA versions
ZD16600	120/240	400	500	430	650	0.7	50	Split phase 3-wire
ZD16601	120/208	400	500	430	650	0.7	50	Three phase 4-wire WYE
ZD16602	120/240	400/800	500/1000	430/770	650/1180	7/1.2	50/68	Three phase 4 wire Delta
ZD16604	277/480	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16607	220/380	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
ZD16608	240/415	800	1000	770	1180	1.2	68	Three phase 4-wire WYE
